MIFAB FDC1.50-QT-LL Image 1

MIFAB FDC1.50-QT-LL BEECO DBL CHECK BACKFLOW 1-1/2IN IPS

MFR Part #: FDC1.50-QT-LL
SKU #: 1119062
Brand: MIFAB®
UPC: 779897201714
MIFAB® BEECO® FDC1.50-QT-LL Small Backflow Preventer, 1-1/2 in Nominal, NPT End Style, Quarter-Turn Shutoff Valve, Bronze Body, Dual Check, Import
1 Year Limited
AB 1953 Compliant | ANSI B1.20.1 | ASSE 1015 | AWWA C510 | CSA B64.5 | IAPMO Listed | Mechanical Contractors Association of America | PDI® Certified | UPC Listed | PROP65: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

MIFAB® BEECO® Backflow Preventer, Low Lead Small, Series: FDC, 1-1/2 in Nominal, NPT, 175 psi, 180 deg F, Quarter-Turn Shutoff Valve Ball Valve/Gate Valve, Dual Check Backflow, Media: Water, Bronze Body, 14-3/4 in L, Import

The BEECO® Friendly Dual Check Backflow Preventer Valve is designed to stop the reverse of flow of a liquid into a potable water system. The proper installation of a backflow preventer must be done by a certified expert under local codes and guidelines to assure the protection of the drinking water system. The Valve shall be certified to ASSE 1015, CSA B64.5 and IAPMO listed.

Product Details

MIFAB® BEECO® Backflow Preventer, Low Lead Small, Series: FDC, 1-1/2 in Nominal, NPT, 175 psi, 180 deg F, Quarter-Turn Shutoff Valve Ball Valve/Gate Valve, Dual Check Backflow, Media: Water, Bronze Body, 14-3/4 in L, Import

The BEECO® Friendly Dual Check Backflow Preventer Valve is designed to stop the reverse of flow of a liquid into a potable water system. The proper installation of a backflow preventer must be done by a certified expert under local codes and guidelines to assure the protection of the drinking water system. The Valve shall be certified to ASSE 1015, CSA B64.5 and IAPMO listed.

Attributes

Backflow Type: Dual Check
Ball Valve/Gate Valve Type: Quarter-Turn Shutoff Valve
Body Material: Bronze
Connection Type: NPT
Country Of Origin: China
Dimensions: 14-3/4 in L
Domestic/Import: Import
Media: Water
Nominal Size: 1-1/2 in
Pressure Rating: 175 psi
Series: FDC
Temperature Rating: 180 deg F
Type: Small

Features

  • Single access cover for fast service
  • Screwed on access cover for quick repair
  • Easily removable check
  • Modular design reducing number of spare part
  • Self-contained check so there is no pressure on the lid

Resources

Instruction/Installation Manual
Specification Sheet
Warranty Information
