AM STD RU101SS SWT/IP ROUGH-IN WITH STOP
Product Details
Attributes
Features
Resources
American Standard, RU101SS, 1/2 in NPT Inlet Connection, 1/2 in NPT Outlet, For Use With: 2-Handle Thermostat Valve, Brass Body, Import
Designed for fast and efficient installation, the flash shower rough-in valve provides flexibility for every situation. The rough-in valve features a flat back and compact body to ensure a secure and simplified install process that can accommodate smaller spaces. Equipped with a test cap, it allows you to install, test and flush lines with ease. Stainless steel fixation ring, with sure-grip flats, keeps test cap and cartridge in place without screws. Cartridge sold separately.
- Cast brass valve body - durable, ideal material for prolonged contact with water
- Flat back - allows valve to be mounted flush against cross brace for easy and solid installation
- Test cap - allows valve body to be tested and flushed without the presence of the valve cartridge, can be tested using test cap with air (200 psi) or water (300 psi)
- Stainless steel retaining ring with flats, secures test cap/cartridge in place and eliminates need for screws, flats make it simple to loosen ring for quick, easy insertion/removal of test cap/cartridge
- Back-to-back capability hot and cold can be reversed quickly and easily
- Exclusive plaster guard - plaster guard is designed to protect valve and act as a guide during installation, it can serve as mounting support for thin-wall installations
- Wide rough-in range - from 1-3/4 to 2-3/4 in from finished wall to the back of the valve
- Includes screwdriver stops for easy servicing at the valve
- Cartridge ships with trim
Product Details
American Standard, RU101SS, 1/2 in NPT Inlet Connection, 1/2 in NPT Outlet, For Use With: 2-Handle Thermostat Valve, Brass Body, Import
Designed for fast and efficient installation, the flash shower rough-in valve provides flexibility for every situation. The rough-in valve features a flat back and compact body to ensure a secure and simplified install process that can accommodate smaller spaces. Equipped with a test cap, it allows you to install, test and flush lines with ease. Stainless steel fixation ring, with sure-grip flats, keeps test cap and cartridge in place without screws. Cartridge sold separately.
Attributes
Features
- Cast brass valve body - durable, ideal material for prolonged contact with water
- Flat back - allows valve to be mounted flush against cross brace for easy and solid installation
- Test cap - allows valve body to be tested and flushed without the presence of the valve cartridge, can be tested using test cap with air (200 psi) or water (300 psi)
- Stainless steel retaining ring with flats, secures test cap/cartridge in place and eliminates need for screws, flats make it simple to loosen ring for quick, easy insertion/removal of test cap/cartridge
- Back-to-back capability hot and cold can be reversed quickly and easily
- Exclusive plaster guard - plaster guard is designed to protect valve and act as a guide during installation, it can serve as mounting support for thin-wall installations
- Wide rough-in range - from 1-3/4 to 2-3/4 in from finished wall to the back of the valve
- Includes screwdriver stops for easy servicing at the valve
- Cartridge ships with trim
