WILKINS 114-375 Image 1

WILKINS 114-375 1-1/4 REDUCED PRESSURE PRINCIPLE ASSY

MFR Part #: 114-375
SKU #: 1053662
Brand: Zurn® | Wilkins
UPC: 612052071589
Zurn® Wilkins 114-375 375 Composite Vessel Backflow Preventer, 1-1/4 in Nominal, FNPT End Style, Quarter-Turn Ball Valve, Ductile Iron Body, Reduced Pressure, 125 lb, Domestic
Potable Water Lines in Fire Protection Systems
Approved by the Foundation for Cross-Connection Control and Hydraulic Research at the University of Southern California | ASSE 1013 | ASTM B584 | AWWA C511 | cUL Listed | IAPMO Listed | UL Listed

Zurn® Wilkins Backflow Preventer, Composite Vessel, Series: 375, 1-1/4 in Nominal, FNPT, 175 psi, 125 lb, 180 deg F, Quarter-Turn Ball Valve Ball Valve/Gate Valve, Reduced Pressure Backflow, Full Port, Media: Water, Ductile Iron Body, Epoxy Coated, Domestic

The Zurn® Wilkins 375 Reduced Pressure Principle Backflow Preventer provides high hazard protection for all applications. The flanged, epoxy coated ductile iron body is available with multiple shut-off valve options for installation versatility.

Product Details

Zurn® Wilkins Backflow Preventer, Composite Vessel, Series: 375, 1-1/4 in Nominal, FNPT, 175 psi, 125 lb, 180 deg F, Quarter-Turn Ball Valve Ball Valve/Gate Valve, Reduced Pressure Backflow, Full Port, Media: Water, Ductile Iron Body, Epoxy Coated, Domestic

The Zurn® Wilkins 375 Reduced Pressure Principle Backflow Preventer provides high hazard protection for all applications. The flanged, epoxy coated ductile iron body is available with multiple shut-off valve options for installation versatility.

Attributes

Backflow TypeReduced Pressure
Connection TypeFNPT
Country Of OriginUS
Nominal Size1-1/4 in
TypeComposite Vessel
Ball Valve/Gate Valve TypeQuarter-Turn Ball Valve
Body MaterialDuctile Iron
Domestic/ImportDomestic
FinishEpoxy Coated
MediaWater
Port TypeFull
Pressure Class125 lb
Pressure Rating175 psi
Series375
Temperature Rating180 deg F

Features

  • Short lay-length for small space installation
  • Ideal for any backflow replacement
  • Utilizes Zurn® Wilkins low headless compound check for reliable and superior performance
  • No threads or taps in body or cover, eliminating exposure to corrosion
  • Single access cover reduces down time
