PHILIPS HCY21L8CST-UN3-DIM Image 1
PHILIPS HCY21L8CST-UN3-DIM Image 2
content loaded
PHILIPS HCY21L8CST-UN3-DIM Image 1

PHILIPS HCY21L8CST-UN3-DIM ROUND HIGH BAY 21000 LUMEN 40/50K DIMMABLEIP65

MFR Part #: HCY21L8CST-UN3-DIM
SKU #: 1232357
Brand: Signify | Day-Brite
UPC: 190096131105
Please note this item is discontinued (order fulfillment will depend on stock availability): Day-Brite HCY21L8CST-UN3-DIM HCY Sealed LED High Bay Fixture LED Lamp, LED Lamp, 150 W Fixture, 120 to 347 VAC, Black Housing
5 years Limited
Industrial Applications
cULus Listed for Wet Locations | DLC Listed | DLC Premium Listed

Day-Brite, HCY21L8CST-UN3-DIM, LED High Bay Fixture LED Lamp, Sealed, Series: HCY, 120 to 347 VAC, 150 W Fixture, LED Lamp, 139 lm/W Light Output, 50000 hr Average Life, 5000 K Color Temperature, 80 CRI, Polycarbonate Lens, 20864 Lumens, NEMA 4X/IP65 Enclosure, Surface Mounting, Black Housing Finish, 11-3/8 in Dia x 8-3/4 in L Dimensions

The Day-Brite/CFI HCY sealed high bay is an ideal choice where functional high bay lighting is needed with an aesthetic appeal. The round form factor lends itself to retail and institutional applications.

Product Details

Day-Brite, HCY21L8CST-UN3-DIM, LED High Bay Fixture LED Lamp, Sealed, Series: HCY, 120 to 347 VAC, 150 W Fixture, LED Lamp, 139 lm/W Light Output, 50000 hr Average Life, 5000 K Color Temperature, 80 CRI, Polycarbonate Lens, 20864 Lumens, NEMA 4X/IP65 Enclosure, Surface Mounting, Black Housing Finish, 11-3/8 in Dia x 8-3/4 in L Dimensions

The Day-Brite/CFI HCY sealed high bay is an ideal choice where functional high bay lighting is needed with an aesthetic appeal. The round form factor lends itself to retail and institutional applications.

Attributes

Average Life: 50000 hr
Clearance Items: Clearance
Color Rendering Index (CRI): 80
Color Temperature: 5000 K
Country Of Origin: China
Dimensions: 11-3/8 in Dia x 8-3/4 in L
Enclosure Type: NEMA 4X/IP65
Fixture Wattage: 150 W
Housing Finish: Black
Lamp Type: LED
Lens Type: Polycarbonate
Light Output: 139 lm/W
Lumens: 20864 Lumens
Mounting Type: Surface
Series: HCY
Type: Sealed
Voltage Rating: 120 to 347 VAC

Features

  • Die cast frame and driver containment housing
  • Corrosion-resistant black finish
  • Heavy duty hook provided for connection to customer supplied suspension
  • Exposed leads for wiring connection with sleeving for environmental protection
  • 6 ft cord provided for power connection and dimming connection
  • 0 to 10 V dimmable universal electronic driver

Resources

Specification Sheet
