PHILIPS 195958 Image 1

PHILIPS 195958 CENTIUM CFL BALLAST 40W 4-PIN 120-277V

MFR Part #: 195958
SKU #: 1116977
Brand: Signify | Advance
UPC: 781087065099
Advance IntelliVolt® CENTIUM SmartMate 195958 Electronic Small Can Ballast, CFL/Long Twin Tube/Parallel Lamp, 40 W Lamp, 120 to 277 VAC, Instant, 0.88 Ballast Factor
This product may be subject to ecological fees.
Outdoor Applications
CEC Certified | CSA Certified | FCC Non-Consumer Approved | UL Listed

Advance IntelliVolt® CENTIUM SmartMate Ballast, Electronic Small Can, CFL/Long Twin Tube/Parallel Lamp, 40 W Lamp, 97 to 99 W Wattage, 120 to 277 VAC, 0.35 to 0.83 A, 50/60 Hz Frequency, Instant Start, 0 deg F Minimum Starting, Total Harmonic Distortion: 0.1 %, Power Factor: 0.98, 3 Lamps, 2G11 Lamp Base, Ballast Factor: 0.88, 70 deg C, Metal, 9.5 in L x 1.7 in W x 1.18 in H Dimensions

Offering maximum versatility, the Philips® Advance family of SmartMate ballasts for 4-pin compact fluorescent lamps drive a broad range of quad and triple-tube, circline, 2D and long twin-tube lamps. SmartMate ballasts' energy efficient design, compact and lightweight housing and user-friendly features make these ballasts an ideal choice for fixture manufacturers, retrofitters and MRO replacement.

Product Details

Advance IntelliVolt® CENTIUM SmartMate Ballast, Electronic Small Can, CFL/Long Twin Tube/Parallel Lamp, 40 W Lamp, 97 to 99 W Wattage, 120 to 277 VAC, 0.35 to 0.83 A, 50/60 Hz Frequency, Instant Start, 0 deg F Minimum Starting, Total Harmonic Distortion: 0.1 %, Power Factor: 0.98, 3 Lamps, 2G11 Lamp Base, Ballast Factor: 0.88, 70 deg C, Metal, 9.5 in L x 1.7 in W x 1.18 in H Dimensions

Offering maximum versatility, the Philips® Advance family of SmartMate ballasts for 4-pin compact fluorescent lamps drive a broad range of quad and triple-tube, circline, 2D and long twin-tube lamps. SmartMate ballasts' energy efficient design, compact and lightweight housing and user-friendly features make these ballasts an ideal choice for fixture manufacturers, retrofitters and MRO replacement.

Attributes

Country Of Origin: Mexico
Lamp Type: CFL/Long Twin Tube/Parallel
Lamp Wattage: 40 W
Number of Lamps: 3
Start Type: Instant
Voltage Rating: 120 to 277 VAC
Amperage Rating: 0.35 to 0.83 A
Ballast Factor: .88
Dimensions: 9.5 in L x 1.7 in W x 1.18 in H
Frequency Rating: 50/60 Hz
Lamp Base Type: 2G11
Material: Metal
Minimum Starting Temperature: 0 deg F
Power Factor: .98
Temperature Range: 70 deg C
Total Harmonic Distortion: .1 %
Type: Electronic Small Can
Wattage: 97 to 99 W

Features

  • Length mounting feet with SmartMate™ dual entry color coded connectors

Resources

Specification Sheet
