ABB TG3222R 60A 2P GD N3R 240V FUSIBLE SWITCH
Product Details
Attributes
Features
Resources
GE Spec-Setter™ Safety Switch, Fusible General Duty, Series: TG Series, 240 VAC, 60 A, 3 hp Standard Fuse/10 hp Time Delay, 1 ph, 50/60 Hz Frequency, 2 Pole, 3 Wires, 100 kA Short Circuit, Handle Actuator, NEMA 3R Enclosure, Surface Mounting, 60/75 deg C, 13.68 in H x 8.4 in W x 3.9 in D Dimensions, Steel
Designed for residential and light commercial applications where duty is not severe. listed to UL standard 98 enclosed and dead front switches. suitable for use as service equipment when installed in accordance with the national electrical code certified to CSA standard 22.2 no 4-04 enclosed and dead front switches. meets or exceeds NEMA KS1 standard for enclosed switches - type GD. fusible and non-fusible switches available (consult BuyLog for interrupt ratings). quick-make, quick-break mechanism (30 to 200 A). 60/75 deg C conductor rating.
- Direct drive, quick-make, quick-break mechanism "snaps" contacts open and closed providing positive on/off indication
- Self-leveling, 3-point mounting system
- Integral cover interlock
- Visible confirmation of plated blade contact positions
- Spring reinforced fuse clips assure reliable contact for cool operation
- Suitable for class H, K, J or R fuses, where applicable
- UL listed short circuit rating is 10000 rms symmetrical amps standard
- With class R fuses and fuse kits installed, 30 to 200 A switches have UL listed short circuit rating of 100000 rms symmetrical A
- UL listed as service entrance equipment when installed in accordance with the national electric code
