TYPE 3AG FAST ACTING (F) 2A 250V FUSES 217 2A (235)
MFR Part #:Â 217 2A
SKU #:Â 1004282
Brand:Â Approved Vendor
UPC:Â 07945890328
U323735 Fast Acting Cartridge Fuse, 250 V, 2 A, 35 A Interrupt, Class: 3AG, Cartridge Body
Used as supplementary protection in appliance or utilization equipment to provide individual protection for components or internal circuits
CE Marked | CCC Marked | cURus E10480 Listed | CSA 29862 Certified | ICC Certified | IEC 60127-2 Certified | RoHS Compliant | UL Listed | VDE 40014645 Approved
Product Details
Attributes
Features
Resources
Fast Acting Cartridge Fuse, 250 V, 2 A, 35 A Interrupt, Class: 3AG, Indicating/Non-Indicating: Non-Indicating, Cartridge Body Type, Holder Mount, Glass Body, Nickel-Plated, -55 to 125 deg C, 0.2 in Dia, 0.78 in Length, Additional Information: 0.041 Ohm Nominal Cold Resistance, 1.6 W Maximum Power Dissipation, 170 mV Maximum Voltage Drop, Lead-Free
Amperage Rating:
2 A
Body Type:
Cartridge
Class:
3AG
Indicating/Non-Indicating:
Non-Indicating
Interrupt Rating:
35 A
Mounting Type:
Holder
Voltage Rating:
250 V
Additional Information:
0.041 Ohm Nominal Cold Resistance, 1.6 W Maximum Power Dissipation, 170 mV Maximum Voltage Drop, Lead-Free
Body Material:
Glass
Diameter:
.2 in
Finish:
Nickel-Plated
Length:
.78 in
Temperature Rating:
-55 to 125 deg C
- Designed to international (IEC) standards for use globally
Product Details
Fast Acting Cartridge Fuse, 250 V, 2 A, 35 A Interrupt, Class: 3AG, Indicating/Non-Indicating: Non-Indicating, Cartridge Body Type, Holder Mount, Glass Body, Nickel-Plated, -55 to 125 deg C, 0.2 in Dia, 0.78 in Length, Additional Information: 0.041 Ohm Nominal Cold Resistance, 1.6 W Maximum Power Dissipation, 170 mV Maximum Voltage Drop, Lead-Free
Attributes
Amperage Rating:Â 2 A
Body Type:Â Cartridge
Class:Â 3AG
Indicating/Non-Indicating:Â Non-Indicating
Interrupt Rating:Â 35 A
Mounting Type:Â Holder
Voltage Rating:Â 250 V
Additional Information:Â 0.041 Ohm Nominal Cold Resistance, 1.6 W Maximum Power Dissipation, 170 mV Maximum Voltage Drop, Lead-Free
Body Material:Â Glass
Diameter:Â .2 in
Finish:Â Nickel-Plated
Length:Â .78 in
Temperature Rating:Â -55 to 125 deg C
Features
- Designed to international (IEC) standards for use globally
