BROAN 509 Image 1

BROAN 509 8IN 180 CFM WALL DAMPER

MFR Part #: 509
SKU #: 0692175
Brand: BROAN
UPC: 026715022892
Broan® 509 Direct Discharge Through Wall Utility Ventilation Fan, 180 cfm, 8-3/8 in Dia Duct, 120 VAC, 1.5 A, Import
1 Year
This product may be subject to ecological fees.
For removing humidity from laundry rooms, tobacco smoke from rec rooms, fumes from workshops or cooking fumes from kitchens
UL Listed | HVI 2100 Certified

Broan® Utility Ventilation Fan, Direct Discharge Through Wall, 180 cfm, 8-3/8 in Duct Dia, 120 VAC, 1.5 A, 60 Hz, 11-1/2 in Grille Length, 11-1/2 in Grille Width, Polymer Grille, 14-1/4 in Housing Width, 14-1/4 in Housing Height, Steel Housing, Wall Mount, No, White, Import

Say goodbye to unbearable heat and humidity in the garage, unwanted smells in the kitchen and odors in the laundry room, rec room or garage. The Broan® 200 CFM Through-Wall Ventilation Fan is the perfect solution for rooms up to 195 sq. ft, including one car garages, or use for spot ventilation near areas such as a work bench, garbage can, car, or lawn mower. The durable galvanized steel housing provides superior protection against the elements and wear and tear. It features a built-in exterior wall cap/vent which reduces install time, no duct work needed. Customize your fan with one of Broan-NuTone’s wall controls. For automatic operation, choose from a humidity or motion sensing control. To automatically turn off the fan after you leave the room or garage, pair the fan with a delay-off or countdown timer. (Wall controls sold separately.)

Product Details

Broan® Utility Ventilation Fan, Direct Discharge Through Wall, 180 cfm, 8-3/8 in Duct Dia, 120 VAC, 1.5 A, 60 Hz, 11-1/2 in Grille Length, 11-1/2 in Grille Width, Polymer Grille, 14-1/4 in Housing Width, 14-1/4 in Housing Height, Steel Housing, Wall Mount, No, White, Import

Say goodbye to unbearable heat and humidity in the garage, unwanted smells in the kitchen and odors in the laundry room, rec room or garage. The Broan® 200 CFM Through-Wall Ventilation Fan is the perfect solution for rooms up to 195 sq. ft, including one car garages, or use for spot ventilation near areas such as a work bench, garbage can, car, or lawn mower. The durable galvanized steel housing provides superior protection against the elements and wear and tear. It features a built-in exterior wall cap/vent which reduces install time, no duct work needed. Customize your fan with one of Broan-NuTone’s wall controls. For automatic operation, choose from a humidity or motion sensing control. To automatically turn off the fan after you leave the room or garage, pair the fan with a delay-off or countdown timer. (Wall controls sold separately.)

Attributes

Amperage Rating: 1.5 A
CFM Rating: 180 cfm
Color: White
Country Of Origin: Mexico
Domestic/Import: Import
Duct Diameter: 8-3/8 in
Duct Size: 8-3/8 in Dia
Flow Rate: 180 cfm
Frequency Rating: 60 Hz
Grille Length: 11-1/2 in
Grille Material: Polymer
Grille Size: 11-1/2 in L x 11-1/2 in W
Grille Width: 11-1/2 in
Housing Height: 14-1/4 in
Housing Material: Steel
Housing Width: 14-1/4 in
Humidity Sensing: No
Material: Steel, Plastic
Mounting Type: Wall
Speed Rating: 1925 rpm
Type: Direct Discharge Through Wall
Voltage Rating: 120 VAC
Width: 8-3/8 in

Features

  • Efficient ventilation for a variety of applications
  • Contemporary styled grille complements modern decor
  • White polymeric grilles can be painted to match any decor
  • Permanently lubricated, thermally protected, plug-in motor
  • Rugged steel housing with modern profile on outer weather hood
  • Ventilator shall be steel housing finished with electrically bonded epoxy paint
  • Specially designed polymeric fan blade
  • Motor assembly offers fast, easy "twist-lock" installation
  • Housing adjusts to fit walls from 4-1/2 to 9-1/2 in THK
  • Built-in backdraft damper
  • Long lasting electrically bonded epoxy coating can be painted to match outdoor styling
  • Built-in rotary switch on model 509S no wall switch to wire
  • 1925 rpm speed, 6.5 Sones sound level
  • Eliminate humidity from laundry rooms, tobacco smoke from recreation rooms and workshops or cooking fumes from kitchens with Broan®’s high efficiency utility ventilators
