LEVITON OSP15-R30 15A 347V POWER PACK FOR OCCUPANCY SENSOR WITH HVAC RELAY EBONY
Product Details
Attributes
Features
Resources
Leviton® Power Pack, Fluorescent, 2 hp, 277 VAC Input, 24 VDC Output, 60 Hz, 120 mA, 0.5 A Relay Rating, 32 to 104 deg F Operating, 0 to 90% Non Condensing Humidity, 3.811 in Width, 1.432 in D, 2.4 in Height, Plastic, Black
Containing both a 24 VDC supply and a 20 A line voltage relay for most models, the Leviton® compact power pack provides low voltage power and line voltage control for Leviton® occupancy Sensors. Versions include auto ON and manual ON inputs for occupancy sensors, hold ON and hold OFF capabilities and a local input for momentary or maintained dry contact switches. The OSP power pack series is also used to supply power to the OSA Add-A-Relay model. The power pack conveniently mounts in a knockout hole of a standard junction box. The unit can be placed inside or outside the junction box with a simple twist on nut. The internal relay can control up to 20 A at either 120, 230 or 277 VAC ballast load, 15 A for 347 VAC ballast load.
- Power supply for all OS series occupancy sensors and add a relay
- Compact size and light weight allows easy mounting through knockout in junction box (from either inside or outside junction box) with a simple twist-on nut, unit is also approved for mounting in ballast channel cavity
- Single or multiple luminaire control from one or more sensors
- Companion Add-A-relay provides additional load capacity
- HVAC relay for signaling energy management systems and controls
- Zero crossing circuitry provides increased durability
- Dry contact relay for combined sensor control of lighting and heating/air conditioning, dry contact for designing controlled closure
Product Details
Leviton® Power Pack, Fluorescent, 2 hp, 277 VAC Input, 24 VDC Output, 60 Hz, 120 mA, 0.5 A Relay Rating, 32 to 104 deg F Operating, 0 to 90% Non Condensing Humidity, 3.811 in Width, 1.432 in D, 2.4 in Height, Plastic, Black
Containing both a 24 VDC supply and a 20 A line voltage relay for most models, the Leviton® compact power pack provides low voltage power and line voltage control for Leviton® occupancy Sensors. Versions include auto ON and manual ON inputs for occupancy sensors, hold ON and hold OFF capabilities and a local input for momentary or maintained dry contact switches. The OSP power pack series is also used to supply power to the OSA Add-A-Relay model. The power pack conveniently mounts in a knockout hole of a standard junction box. The unit can be placed inside or outside the junction box with a simple twist on nut. The internal relay can control up to 20 A at either 120, 230 or 277 VAC ballast load, 15 A for 347 VAC ballast load.
Attributes
Features
- Power supply for all OS series occupancy sensors and add a relay
- Compact size and light weight allows easy mounting through knockout in junction box (from either inside or outside junction box) with a simple twist-on nut, unit is also approved for mounting in ballast channel cavity
- Single or multiple luminaire control from one or more sensors
- Companion Add-A-relay provides additional load capacity
- HVAC relay for signaling energy management systems and controls
- Zero crossing circuitry provides increased durability
- Dry contact relay for combined sensor control of lighting and heating/air conditioning, dry contact for designing controlled closure
