LUTRON MSCL-OP153MH-WHC MAESTRO W/PIR SNSR 1PL/3WAY LED/CFL
Product Details
Attributes
Features
Resources
Lutron®, MSCL-OP153MH-WHC, Occupancy Sensing CL Dimmer, 1-Pole Multi-Location, Series: Maestro®, 120 VAC, 1.25 A, 150 W Power, Passive Infrared Sensor, 400 sq-ft Minor, 900 sq-ft Major Coverage, 180 deg Viewing, 10 s Time Delay, CFL/Halogen/Incandescent/LED Lamp, 60 Hz Response, Ground Connection, Manual On/Automatic Off/Automatic On/Automatic Off Control Output, NEMA WD7 Enclosure, Wall Mounting, 32 to 104 deg F, Natural White, 4-11/16 in H x 2-15/16 in W x 1-1/8 in D Dimensions
Lutron® Maestro® occupancy sensor CL dimmers are lighting controls with passive infrared sensors that automatically control the lights in an area. These sensors detect heat from occupants moving within an area to determine when the space is occupied. The
- Controls CFL, LED, incandescent and halogen load types
- Auto-ON/OFF, Manual-ON/Auto-OFF switch operation
- Off warning fades lights to off over a period of 10 s
- Up to 30 x 30 ft (9 x 9 m) 900 sq-ft (81 sq-m) major motion coverage and 20 x 20 ft (6 x 6 m) 400 sq-ft (36 sq-m) minor motion coverage
- Adjustable settings for auto-on light level (occupied level) 100%, 50%, last light level or locked preset light level
- Adjustable timeout (1, 3, 5, 15 or 30 min) and high/low sensitivity adjustment
- Works with a single standard mechanical 3-way switch or up to 9 companion dimmers/switches (MA-R or MSC-AD)
- Passive infrared motion detection with exclusive Lutron® XCT™ Technology for fine motion detection
- Residential grade
Product Details
Lutron®, MSCL-OP153MH-WHC, Occupancy Sensing CL Dimmer, 1-Pole Multi-Location, Series: Maestro®, 120 VAC, 1.25 A, 150 W Power, Passive Infrared Sensor, 400 sq-ft Minor, 900 sq-ft Major Coverage, 180 deg Viewing, 10 s Time Delay, CFL/Halogen/Incandescent/LED Lamp, 60 Hz Response, Ground Connection, Manual On/Automatic Off/Automatic On/Automatic Off Control Output, NEMA WD7 Enclosure, Wall Mounting, 32 to 104 deg F, Natural White, 4-11/16 in H x 2-15/16 in W x 1-1/8 in D Dimensions
Lutron® Maestro® occupancy sensor CL dimmers are lighting controls with passive infrared sensors that automatically control the lights in an area. These sensors detect heat from occupants moving within an area to determine when the space is occupied. The
Attributes
Features
- Controls CFL, LED, incandescent and halogen load types
- Auto-ON/OFF, Manual-ON/Auto-OFF switch operation
- Off warning fades lights to off over a period of 10 s
- Up to 30 x 30 ft (9 x 9 m) 900 sq-ft (81 sq-m) major motion coverage and 20 x 20 ft (6 x 6 m) 400 sq-ft (36 sq-m) minor motion coverage
- Adjustable settings for auto-on light level (occupied level) 100%, 50%, last light level or locked preset light level
- Adjustable timeout (1, 3, 5, 15 or 30 min) and high/low sensitivity adjustment
- Works with a single standard mechanical 3-way switch or up to 9 companion dimmers/switches (MA-R or MSC-AD)
- Passive infrared motion detection with exclusive Lutron® XCT™ Technology for fine motion detection
- Residential grade
