GRUNDFOS 99631742 SCALA1 3-45 CSA 1 X 115 V 60 HZ

Name: GRUNDFOS 99631742 SCALA1 3-45 CSA 1 X 115 V 60 HZ
Brand: Grundfos
SKU: 1243130
Availability: InStock

MFR Part #: 99631742

SKU #: 1243130

Brand: Grundfos

UPC: 400050280344

Grundfos SCALA Series 99631742 Pressure Booster Pump, 1 in Inlet, 1 in Outlet, Composite

2 Year

Commercial Water Pressure Boosting, Domestic Ground Water Intake, Domestic Water Pressure Boosting and Domestic Rainwater Harvesting Applications

cCSAus Certified|CSA DW Certified

Product Details
Attributes
Resources

Grundfos Pressure Booster Pump, SCALA Series, 115 VAC, 8.62 A, 0.791 hp Horsepower Rating, 950 W Wattage, 14.9 gpm Flow Rate, 1 in Inlet, 1 in Outlet, 46 m Head, Class F Motor Duty Class, 8 bar Working Pressure Rating, 0 to 55 deg C, NEMA X4D Enclosure, Composite, 12.4 in H x 7.95 in W

SCALA1 is a fully intergrated, compact self-priming, pressure booster for domestic use. It can communicate with Grundfos GO remote app via built-in Bluetooth technology enabling high customization options.

Product Details

Grundfos Pressure Booster Pump, SCALA Series, 115 VAC, 8.62 A, 0.791 hp Horsepower Rating, 950 W Wattage, 14.9 gpm Flow Rate, 1 in Inlet, 1 in Outlet, 46 m Head, Class F Motor Duty Class, 8 bar Working Pressure Rating, 0 to 55 deg C, NEMA X4D Enclosure, Composite, 12.4 in H x 7.95 in W

SCALA1 is a fully intergrated, compact self-priming, pressure booster for domestic use. It can communicate with Grundfos GO remote app via built-in Bluetooth technology enabling high customization options.

Attributes

Amperage Rating: 8.62 A

Dimensions: 12.4 in H x 7.95 in W

Enclosure Type: NEMA X4D

Flow Rate: 14.9 gpm

Head Size: 46 m

Horsepower Rating: .791 hp

Inlet Size: 1 in

Material: Composite

Motor Duty Class: Class F

Outlet Size: 1 in

Series: SCALA Series

Temperature Rating: 0 to 55 deg C

Voltage Rating: 115 VAC

Wattage: 950 W

Working Pressure Rating: 8 bar

Resources

Instruction/Installation Manual
