TACO VM1212-DY1-UP2A01 Image 1

TACO VM1212-DY1-UP2A01 ECM DHW CIRCULATOR WITH LINECORD

MFR Part #: VM1212-DY1-UP2A01
SKU #: 1218322
Brand: Taco® Comfort Solutions™
UPC: 190145491181
Taco Comfort Solutions® 006e3 Series 006e3LC VM1212-DY1-UP2A01 High-Efficiency Circulator Pump, 11 gpm, 44 W, 120 VAC
Limited
Power Cord
For open loop potable water systems and closed hydronic systems
cULus Listed|FCC Approved|NSF Certified

Taco Comfort Solutions® High-Efficiency Circulator Pump, 006e3 Series, Model: 006e3LC, 11 gpm Flow Rate, 13 ft Maximum Head, 44 W, 120 VAC, 0.54 A, 60 Hz, 150 psi Maximum Pressure, 1440 to 3720 rpm Motor Speed Rating, 1/40 hp, 1 in Connection, Union Connection, 1 ph Phase, Foot Mounting, 36 to 230 deg F, Composite, 5-1/8 in H x 5-1/8 in W x 5-1/2 in D, Additional Information: ECM, Permanent Magnet, Thermally Protected Motor, Composite Impeller Material

The 00e Series - 006e3 is an infinitely variable, high-efficiency wet rotor circulator with an ECM permanent magnet motor. With 3-easy settings, the 006e3 delivers performance, reliability and ease of installation that made the 00 famous.

Product Details

Taco Comfort Solutions® High-Efficiency Circulator Pump, 006e3 Series, Model: 006e3LC, 11 gpm Flow Rate, 13 ft Maximum Head, 44 W, 120 VAC, 0.54 A, 60 Hz, 150 psi Maximum Pressure, 1440 to 3720 rpm Motor Speed Rating, 1/40 hp, 1 in Connection, Union Connection, 1 ph Phase, Foot Mounting, 36 to 230 deg F, Composite, 5-1/8 in H x 5-1/8 in W x 5-1/2 in D, Additional Information: ECM, Permanent Magnet, Thermally Protected Motor, Composite Impeller Material

The 00e Series - 006e3 is an infinitely variable, high-efficiency wet rotor circulator with an ECM permanent magnet motor. With 3-easy settings, the 006e3 delivers performance, reliability and ease of installation that made the 00 famous.

Attributes

Additional Information: ECM, Permanent Magnet, Thermally Protected Motor, Composite Impeller Material
Amperage Rating: .54 A
Body Material: Composite
Connection Size: 1 in
Connection Type: Union
Cord Length: 6 ft
Dimensions: 5-1/8 in H x 5-1/8 in W x 5-1/2 in D
Flow Rate: 11 gpm
Frequency Rating: 60 Hz
HP Rating: 1/40 hp
Impeller Material: Composite
Material: Composite
Maximum Head: 13 ft
Maximum Pressure: 150 psi
Model: 006e3LC
Motor Speed Rating: 1440 to 3720 rpm
Motor Type: ECM, Permanent Magnet, Thermally Protected
Mounting Type: Foot
Phase: 1 ph
Power Rating: 44 W
Pressure Rating: 150 psi
Series: 006e3 Series
Speed Rating: 1440 to 3720 rpm
Temperature Rating: 36 to 230 deg F
Voltage Rating: 120 VAC

Features

  • Taco trusted 00e Series quality and reliability
  • Easy-to-use dial - low, medium, high - 003 and 006 performance, point references
  • Easy installation compact design for tight spaces
  • High-efficiency ECM motor uses up to 85% less electricity
  • SureStart® automatic unblocking and air purging mode
  • Rugged high-performance composite casing
  • 3-color LED indicator light: blue - operating mode, white - SureStart®, red - error diagnostic
  • Whisper quiet operation
