GRUNDFOS 59896341 1/25HP 115V CI 3SP CP W/CV UPS15-58FC

MFR Part #: 59896341
SKU #: 1003884
Brand: Grundfos
UPC: 5700395855203
Grundfos VersaFlo® 59896341 UPS Canned Rotor Circulator Pump, 115 VAC, 1 ph
85904401 Motor
1 and 2-Pipe Heating Systems, Main Pumps, Zone Pumps, Boiler Shunt Pumps, Pumps for Heating Surfaces, Calorifiers, Underfloor Heating Systems, Solar Heating Systems, Heat Pump Systems, Geothermal Heating Systems, Heat Recovery Systems, 2-Pipe Air-Conditioning Systems and Pumps for Refrigeration Units
ASTM 30 B|CSA Certified|UL Listed

Grundfos VersaFlo® Circulator Pump, Canned Rotor, Series: UPS, 19.36 ft Maximum Head, 87 W, 115 VAC, 0.55 to 0.75 A, 60 Hz, 1 ph, 145 psi Maximum, Composite PES Impeller, 140 deg F, Ceramic Radial/Carbon Thrust Bearing, 5-1/4 in W x 6-1/2 in H

UPS pumps constitute a complete range of 3-speed circulator pumps, available both in 50 and 60 Hz. The pumps can be used in both open and closed systems. UPS pumps are of the canned rotor type, i.e. pump and motor form an integral unit without a shaft seal and with only two gaskets for sealing. The bearings are lubricated by the pumped liquid.

Product Details

Grundfos VersaFlo® Circulator Pump, Canned Rotor, Series: UPS, 19.36 ft Maximum Head, 87 W, 115 VAC, 0.55 to 0.75 A, 60 Hz, 1 ph, 145 psi Maximum, Composite PES Impeller, 140 deg F, Ceramic Radial/Carbon Thrust Bearing, 5-1/4 in W x 6-1/2 in H

UPS pumps constitute a complete range of 3-speed circulator pumps, available both in 50 and 60 Hz. The pumps can be used in both open and closed systems. UPS pumps are of the canned rotor type, i.e. pump and motor form an integral unit without a shaft seal and with only two gaskets for sealing. The bearings are lubricated by the pumped liquid.

Attributes

Amperage Rating: 0.55 to 0.75 A
Bearing Type: Ceramic Radial/Carbon Thrust
Country Of Origin: US
Dimensions: 5-1/4 in W x 6-1/2 in H
Frequency Rating: 60 Hz
HP Rating: 1/25 hp
Impeller Type: Composite PES
Maximum Head: 19.36 ft
Maximum Pressure: 145 psi
Phase: 1
Power Rating: 87 W
Series: UPS
Temperature Rating: 140 deg F
Type: Canned Rotor
Voltage Rating: 115 VAC

Features

  • Maintenance-free
  • Low noise and low energy
  • Complete range and wide range of accessories
  • Stainless steel rotor can and bearing plate
  • Corrosion-resistant impeller
  • No additional motor protection is required
  • Non-electronically controlled circulator pumps for domestic building with speed control
  • Removable check valve
  • Flange pipe connection
  • Cast iron pump housing
  • Small stator
  • 3-speed motor
