GRUNDFOS 59896773 1/25HP 115V SS 3SP CIRC PUMP UPS15-55SFC
Product Details
Attributes
Features
Resources
Grundfos Circulator Pump, Series: UPS, 25.1 gpm, 18.05 ft Maximum Head, 87 W, 115 VAC, 0.53 to 0.75 A, 60 Hz, 1 ph, 145 psi Maximum, 104 deg F, 5-8/16 in W x 6-8/16 in H
The pump is of the canned rotor type, i.e. pump and motor form an integral unit without shaft seal and with only two gaskets for sealing. The bearings are lubricated by the pumped liquid. The pump has 3-step speed selector.
- Ceramic shaft and radial bearings
- Carbon axial bearing
- Stainless steel rotor can and bearing plate
- Corrosion resistant impeller, composite, PES
- Stainless steel pump housing
- 1 ph motor, no additional motor protection is required
Product Details
Grundfos Circulator Pump, Series: UPS, 25.1 gpm, 18.05 ft Maximum Head, 87 W, 115 VAC, 0.53 to 0.75 A, 60 Hz, 1 ph, 145 psi Maximum, 104 deg F, 5-8/16 in W x 6-8/16 in H
The pump is of the canned rotor type, i.e. pump and motor form an integral unit without shaft seal and with only two gaskets for sealing. The bearings are lubricated by the pumped liquid. The pump has 3-step speed selector.
Attributes
Features
- Ceramic shaft and radial bearings
- Carbon axial bearing
- Stainless steel rotor can and bearing plate
- Corrosion resistant impeller, composite, PES
- Stainless steel pump housing
- 1 ph motor, no additional motor protection is required
