LITTLE GIANT 558556 W5G10S21-32P 5GPM 1HP 21STG 3WIRE 230V
MFR Part #:Â 558556
SKU #:Â 1153128
Brand: Little Giant®
UPC:Â 010121118416
Please note this item is discontinued (order fulfillment will depend on stock availability): Little Giant® 558556 21-Stage Submersible Deep Well Pump, 5 gpm Flow Rate, 1-1/4 in FNPT Outlet, 1 ph, 1 hp, Stainless Steel, Import
2 Years
Motor
For both new installs and replacement applications where water must be transferred under pressure from wells, cisterns, ponds, lakes and streams
ANSI/NSF 372|cCSAus Certified|UL 778
Product Details
Attributes
Features
Resources
Little Giant® Submersible Deep Well Pump, 21-Stage, 5 gpm, 1-1/4 in FNPT Outlet, 614 ft Maximum Head, 1 hp, 230 V, 60 Hz Frequency, 1 ph ph, 3-Wire Cord, Sleeve Bearing, Stainless Steel, 4 in Dia x 35.63 in H Dimensions, Import
Clearance Items:
Clearance
Country Of Origin:
Mexico
Flow Rate:
5 gpm
Horsepower:
1 hp
Maximum Head:
614 ft
Outlet Size:
1-1/4 in FNPT
Voltage Rating:
230 V
Bearing Type:
Sleeve
Cord Type:
3-Wire
Dimensions:
4 in Dia x 35.63 in H
Domestic/Import:
Import
Frequency Rating:
60 Hz
Material:
Stainless Steel
Phase:
1
Type:
21-Stage
- Removable suction screen prevents debris from clogging impellers and provides full-flow performance
- Hex rubber bearing has multi-flow channels to keep small particles away from bearing surface
- Built-in Flomatic™ check valve assembly provides positive seal, preventing system drain-back
- Stainless steel bearing sleeve
- Acetal disk facilitates close tolerances for increased performance
- Stainless steel up-thrust washer prevents excessive wear in service applications
- Thermoplastic discharge
Product Details
Little Giant® Submersible Deep Well Pump, 21-Stage, 5 gpm, 1-1/4 in FNPT Outlet, 614 ft Maximum Head, 1 hp, 230 V, 60 Hz Frequency, 1 ph ph, 3-Wire Cord, Sleeve Bearing, Stainless Steel, 4 in Dia x 35.63 in H Dimensions, Import
Attributes
Clearance Items:Â Clearance
Country Of Origin:Â Mexico
Flow Rate:Â 5 gpm
Horsepower:Â 1 hp
Maximum Head:Â 614 ft
Outlet Size:Â 1-1/4 in FNPT
Voltage Rating:Â 230 V
Bearing Type:Â Sleeve
Cord Type:Â 3-Wire
Dimensions:Â 4 in Dia x 35.63 in H
Domestic/Import:Â Import
Frequency Rating:Â 60 Hz
Material:Â Stainless Steel
Phase:Â 1
Type:Â 21-Stage
Features
- Removable suction screen prevents debris from clogging impellers and provides full-flow performance
- Hex rubber bearing has multi-flow channels to keep small particles away from bearing surface
- Built-in Flomatic™ check valve assembly provides positive seal, preventing system drain-back
- Stainless steel bearing sleeve
- Acetal disk facilitates close tolerances for increased performance
- Stainless steel up-thrust washer prevents excessive wear in service applications
- Thermoplastic discharge
