LEVITON 2326 Image 1

LEVITON 02326-068-000 20A 250V 2-POLE 3-WIRE FLANGED OUTLET WHITE

MFR Part #: 2326
SKU #: 1022013
Brand: Leviton®
UPC: 7847780118
Leviton® 2326 Grounding Receptacle Locking Flanged Outlet, 250 VAC, 20 A, 2 Poles, 3 Wires, White
Lifetime
Commercial Applications
ANSI C73 | CSA C22.2 No.42 File No. LR406 | NOM 057 | NEMA WD1/WD6 | UL 498 File No. E13393 | UL94 V-2 Flammability Rating

Leviton®, 2326, Locking Flanged Outlet, Grounding Receptacle, 250 VAC, 20 A, 2 hp, 2 Pole, 3 Wires, NEMA L7-20R NEMA Rating, Industrial Grade, -40 to 60 deg C, Back Wire Terminal, Nylon, White, 2.5 in Dia x 1.78 in H Dimensions

Leviton® industry leading locking devices, such as our Black & White® line of industrial grade plugs and connectors and our V-0-Max™ line of industrial grade flush receptacles, offer superior performance, long lasting reliability and other features that are backed by a lifetime warranty.

Product Details

Leviton®, 2326, Locking Flanged Outlet, Grounding Receptacle, 250 VAC, 20 A, 2 hp, 2 Pole, 3 Wires, NEMA L7-20R NEMA Rating, Industrial Grade, -40 to 60 deg C, Back Wire Terminal, Nylon, White, 2.5 in Dia x 1.78 in H Dimensions

Leviton® industry leading locking devices, such as our Black & White® line of industrial grade plugs and connectors and our V-0-Max™ line of industrial grade flush receptacles, offer superior performance, long lasting reliability and other features that are backed by a lifetime warranty.

Attributes

Amperage Rating: 20 A
Country Of Origin: US
Color: White
Dimensions: 2.5 in Dia x 1.78 in H
Grade: Industrial
Horsepower: 2 hp
Material: Nylon
NEMA Rating: NEMA L7-20R
Number of Poles: 2
Number of Wires: 3
Temperature Rating: -40 to 60 deg C
Terminal Type: Back Wire
Type: Grounding Receptacle
Voltage Rating: 250 VAC

Features

  • 14 to 8 AWG terminal accommodation, grounding
  • 2000 VAC minimum dielectric strength
  • Maximum 30 deg C after 250 cycles OL at 200% rated current temperature rise
  • Nylon face material, brass 0.035 in THK line contacts
  • #10-32 brass terminal screws
  • #8-32 brass grounding screws
  • Thermoplastic nylon strap
  • Brass-hot, green ground, white-neutral terminal ID
  • Ratings are permanently marked on device product ID
  • Rugged nylon flange fits flush and wont crack in high abuse applications
  • Individual deep-funneled chamfered wire wells guide each wire into rectangular chambers
  • Wire clamps bundle stranded wire without cutting wire strands

Resources

Catalog
Specification Sheet
