ABB LS35P10B11 Image 1
ABB LS35P10B11 Image 2
ABB LS35P10B11 Image 3
content loaded
ABB LS35P10B11 Image 1

ABB LS35P10B11 PLAST LIM SW 30MM PLAST PLAIN PLUNGER

MFR Part #: LS35P10B11
SKU #: 1041542
Brand: ABB
UPC: 662019788029
ABB LS35P10B11 LS Series Standard Limit Switch, 24/130/230/240/400 VAC, 24/110/250 VDC, 0.27/0.6/1.8/2.8/3/3.1/5.5/10 A, Plain Plunger Actuator, 1NC-1NO Contact
For presence/absence, positioning and travel limit, objects passing/counting mechanical applications

ABB, LS35P10B11, Limit Switch, Standard, Series: LS Series, 24/130/230/240/400 VAC, 24/110/250 VDC, 0.27/0.6/1.8/2.8/3/3.1/5.5/10 A, 50/60 Hz Frequency, 1NC-1NO Contact Configuration, 10 A at 24 V Contact, 25 mOhm Closed Contact Resistance, Snap Action, Plain Plunger Actuator, 1/2 in NPT Connection, Class II Insulation, NEMA 4/IP65 Enclosure, Threaded Mounting, 30 mm W Size, 3600 Cycles/hr Operating Cycles, -25 to 70 deg C Operating, Plastic, Environmental Conditions: -30 to 80 deg C Storage Temperature

LS35P10B11 is a 30 mm W, standard Limit Switch made of fiber-glass reinforced UL-V0 material, with 2 mounting holes at the top, 1-1/2 in NPT cable entry on the bottom, plain plastic plunger actuator and 1 NO + 1 NC snap action (Zb type) contacts.

Product Details

ABB, LS35P10B11, Limit Switch, Standard, Series: LS Series, 24/130/230/240/400 VAC, 24/110/250 VDC, 0.27/0.6/1.8/2.8/3/3.1/5.5/10 A, 50/60 Hz Frequency, 1NC-1NO Contact Configuration, 10 A at 24 V Contact, 25 mOhm Closed Contact Resistance, Snap Action, Plain Plunger Actuator, 1/2 in NPT Connection, Class II Insulation, NEMA 4/IP65 Enclosure, Threaded Mounting, 30 mm W Size, 3600 Cycles/hr Operating Cycles, -25 to 70 deg C Operating, Plastic, Environmental Conditions: -30 to 80 deg C Storage Temperature

LS35P10B11 is a 30 mm W, standard Limit Switch made of fiber-glass reinforced UL-V0 material, with 2 mounting holes at the top, 1-1/2 in NPT cable entry on the bottom, plain plastic plunger actuator and 1 NO + 1 NC snap action (Zb type) contacts.

Attributes

Action: Snap
Actuator: Plain Plunger
Amperage Rating: 0.27/0.6/1.8/2.8/3/3.1/5.5/10 A
Closed Contact Resistance: 25 mOhm
Connection Type: 1/2 in NPT
Contact Configuration: 1NC-1NO
Enclosure Type: NEMA 4/IP65
Environmental Conditions: -30 to 80 deg C Storage Temperature
Frequency Rating: 50/60 Hz
Insulation Type: Class II
Material: Plastic
Mounting Type: Threaded
Operating Cycles: 3600 Cycles/hr
Operating Temperature: -25 to 70 deg C
Series: LS Series
Size: 30 mm W
Voltage Rating: 24 to 130 to 230 to 240 to 400 VAC/24 to 110 to 250 VDC
Contact Rating: 10 A at 24 V
Type: Standard

Features

  • 10 A at 24 VAC, 5.5 A at 130 VAC, 3.1 A at 230 VAC, 3 A at 240 VAC, 1.8 A at 400 VAC at AC-15, 2.8 A at 24 VDC, 0.6 A at 110 VDC, 0.27 A at 250 VDC at DC-13
  • (2) Mounting holes at the top
  • 0.55 A at 125 V, 6 A at 24 V, 0.4 A at 250 V, 0.6 A at 110 V rated operational current DC-13
  • Immune to electromagnetic disturbances
  • Able to switch strong currents (10 A conventional thermal current)
  • Precise operating points (consistency)
  • Electrically separated contacts
  • Visible operation
